RL78/F13, F14 CHAPTER 2 PIN FUNCTIONS

R01UH0368EJ0210 Rev.2.10 87

Dec 10, 2015

Pin Name I/O Recommended Connection of Unused Pins

P121/X1 Input Independently connect to VDD or VSS via a resistor.

P122/X2/EXCLK

P123/XT1

P124/XT2/EXCLKS

P125/ANI24/TI03/TO03/TRDIOB0/SSI01/

INTP1/SNZOUT1

I/O Input: Independently connect to EVDD0 or EVSS0 via a resistor.

Output: Leave open.

P126/(TI01)/(TO01)

P130/RESOUT Output Leave open.

P137/INTP0 Input Independently connect to VDD or VSS via a resistor.

P140/PCLBUZ0 I/O Input: Independently connect to EVDD0 or EVSS0 via a resistor.

Output: Leave open.

RESET Input Connect to VDD directly or via a resistor.

REGC



Connect to VSS via a capacitor (0.47 to 1 µF).

Remark Functions in parentheses in the above table can be assigned via settings in the peripheral I/O redirection

registers (PIOR).
