Renesas RL78 Series User Manual

RL78/F13, F14 CHAPTER 17 LIN/UART MODULE (RLIN3)
R01UH0368EJ0210 Rev.2.10 1254
Dec 10, 2015
Table 17-29. Examples of Baud Rate Generation (19200 bps, 10417 bps, 9600 bps and 2400 bps) in
LIN Slave Mode [Fixed Baud Rate]
LIN
communication
clock source
Prescaler
Baud rate generator 0-1
N+1 frequency-divided
Baud rate Error
32 MHz 1/1 104 19230.77 +0.16%
192 10416.67 -0.003%
208 9615.38 +0.16%
833 2400.96 +0.04%
24 MHz 1/1 78 19230.77 +0.16%
144 10416.67 -0.003%
156 9615.38 +0.16%
625 2400 0%
16 MHz 1/1 52 19230.77 +0.16%
96 10416.67 -0.003%
104 9615.38 +0.16%
417 2398.08 -0.08%
12 MHz 1/1 39 19230.77 +0.16%
72 10416.67 -0.003%
78 9615.38 +0.16%
313 2396.17 -0.16%
8 MHz 1/1 26 19230.77 +0.16%
48 10416.67 -0.003%
52 9615.38 +0.16%
208 2403.85 +0.16%
Remark The numbers in the table are for sixteen samples per bit (i.e. when NSPB[3:0] = 0000b or 1111b).

Renesas RL78 Series Specifications

General

Core	RL78
CPU Clock Speed	Up to 32 MHz
Flash Memory	Up to 512 KB
RAM	Up to 32 KB
Operating Voltage	1.6 V to 5.5 V
Low Power Modes	HALT, STOP, SNOOZE
CPU Architecture	16-bit
Temperature Range	-40°C to +85°C
Package	LQFP
Timers	16-bit timers
Communication Interfaces	UART, I2C, LIN
A/D Converter	12-bit
