RL78/F13, F14 CHAPTER 18 CAN INTERFACE (RS-CAN LITE)
R01UH0368EJ0210 Rev.2.10 1264
Dec 10, 2015
Table 18-3. List of CAN Module Registers (2/22)
Address Special Function Register (SFR) Name Symbol R/W Access Size After
Reset
1 bit 8 bits 16 bits
F0340H CAN receive FIFO status register 0 RFSTS0L RFSTS0 R/W — √ √ 0001H
Note
F0341H RFSTS0H R — √
F0342H CAN receive FIFO status register 1 RFSTS1L RFSTS1 R/W — √ √ 0001H
Note
F0343H RFSTS1H R — √
F0348H CAN receive FIFO pointer control register 0 RFPCTR0L RFPCTR0 W — √ √ 0000H
F0349H RFPCTR0H — √
F034AH CAN receive FIFO pointer control register 1 RFPCTR1L RFPCTR1 W — √ √ 0000H
F034BH RFPCTR1H — √
F0350H CAN0 transmit/receive FIFO control
register 0L
CFCCL0L CFCCL0 R/W — √ √ 0000H
F0351H CFCCL0H — √
F0352H CAN0 transmit/receive FIFO control
register 0H
CFCCH0L CFCCH0 R/W — √ √ 0000H
F0353H CFCCH0H — √
F0358H CAN0 transmit/receive FIFO status register
0
CFSTS0L CFSTS0 R/W — √ √ 0001H
Note
F0359H CFSTS0H R — √
F035CH CAN0 transmit/receive FIFO pointer control
register 0
CFPCTR0L CFPCTR0 W — √ √ 0000H
F035DH — — —
F0360H Receive FIFO message lost status register RFMSTS R — √ — 00H
F0361H CAN0 transmit/receive FIFO message lost
status register
CFMSTS R — √ — 00H
F0362H CAN receive FIFO interrupt status register RFISTS R — √ — 00H
F0363H CAN transmit/receive FIFO receive
interrupt status register
CFISTS R — √ — 00H
F0364H CAN0 transmit buffer control register 0 TMC0 R/W — √ — 00H
F0365H CAN0 transmit buffer control register 1 TMC1 R/W — √ — 00H
F0366H CAN0 transmit buffer control register 2 TMC2 R/W — √ — 00H
F0367H CAN0 transmit buffer control register 3 TMC3 R/W — √ — 00H
F036CH CAN0 transmit buffer status register 0 TMSTS0 R/W — √ — 00H
F036DH CAN0 transmit buffer status register 1 TMSTS1 R/W — √ — 00H
F036EH CAN0 transmit buffer status register 2 TMSTS2 R/W — √ — 00H
F036FH CAN0 transmit buffer status register 3 TMSTS3 R/W — √ — 00H
F0374H CAN0 transmit buffer transmit request
status register
TMTRSTSL TMTRSTS R — √ √ 0000H
F0375H TMTRSTSH — √
F0376H CAN0 transmit buffer transmit complete
status register
TMTCSTSL TMTCSTS R — √ √ 0000H
F0377H TMTCSTSH — √
F0378H CAN0 transmit buffer transmit abort status
register
TMTASTSL TMTASTS R — √ √ 0000H
F0379H TMTASTSH — √
F037AH CAN0 transmit buffer interrupt enable
register
TMIECL TMIEC R/W — √ √ 0000H
F037BH TMIECH — √
F037CH CAN0 transmit history buffer control
register
THLCC0L THLCC0 R/W — √ √ 0000H
F037DH THLCC0H — √
F0380H CAN0 transmit history buffer status register THLSTS0L THLSTS0 R/W — √ √ 0001H
Note
F0381H THLSTS0H — √
F0384H CAN0 transmit history buffer pointer control
register
THLPCTR0L THLPCTR0 W — √ √ 0000H
F0385H THLPCTR0H — √
F0388H CAN global transmit interrupt status
register
GTINTSTSL GTINTSTS R — √ √ 0000H
F0389H GTINTSTSH — √
Note When the CAN0EN bit in the PER2 register is set to 0, the read value is undefined.
When the CAN0EN bit in the PER2 register is set to 1, the read value is the initial value listed above.
