RL78/F13, F14 CHAPTER 18 CAN INTERFACE (RS-CAN LITE)

R01UH0368EJ0210 Rev.2.10 1406

Dec 10, 2015

Table 18-14. Example of Communication Speed Setting

fCAN

Note

Communication Speed

16 MHz 8 MHz

1 Mbps 8 Tq (2)

16 Tq (1)

8 Tq (1)

500 Kbps 8 Tq (4)

16 Tq (2)

8 Tq (2)

16 Tq (1)

250 Kbps 8 Tq (8)

16 Tq (4)

8 Tq (4)

16 Tq (2)

83.3 Kbps 8 Tq (24)

16 Tq (12)

8 Tq (12)

16 Tq (6)

33.3 Kbps 8 Tq (60)

10 Tq (48)

16 Tq (30)

20 Tq (24)

8 Tq (30)

10 Tq (24)

16 Tq (15)

20 Tq (12)

Note Values in ( ) are baud rate prescaler division values.
