Renesas RL78 Series User Manual

RL78/F13, F14 CHAPTER 3 CPU ARCHITECTURE
R01UH0368EJ0210 Rev.2.10 115
Dec 10, 2015
Table 3-3. Vector Table (1/2)
Vector Table Address Interrupt Source 100-pin 80-pin 64-pin 48-pin 32-pin 30-pin 20-pin
0000H
RESET, POR, LVD, WDT,
TRAP, IAW, CLM
      
0004H INTWDTI       
0006H INTLVI       
0008H INTP0       
000AH INTP1       
000CH INTP2       
000EH INTP3       
0010H INTP4/INTSPM       
0012H INTP5/INTCMP0       
0014H INTP13       
INTCLM       
0016H INTST0       
INTCSI00       
INTIIC00       
0018H INTSR0       
INTCSI01       
INTIIC01       
001AH INTTRD0       
001CH INTTRD1       
001EH INTTRJ0       
0020H INTRAM       
0022H INTLIN0TRM       
0024H INTLIN0RVC       
0026H INTLIN0STA/INTLIN0       
0028H INTIICA0       
002AH INTP8       
INTRTC       
002CH INTTM00       
002EH INTTM01       
0030H INTTM02       
0032H INTTM03       
0034H INTAD       
0036H INTP6       
INTTM11H       
0038H INTP7       
INTTM13H       
003AH INTP9       
INTTM01H       
003CH INTP10       
INTTM03H       
003EH INTST1       
INTCSI10       
INTIIC10       

Renesas RL78 Series Specifications

General

Core	RL78
CPU Clock Speed	Up to 32 MHz
Flash Memory	Up to 512 KB
RAM	Up to 32 KB
Operating Voltage	1.6 V to 5.5 V
Low Power Modes	HALT, STOP, SNOOZE
CPU Architecture	16-bit
Temperature Range	-40°C to +85°C
Package	LQFP
Timers	16-bit timers
Communication Interfaces	UART, I2C, LIN
A/D Converter	12-bit
