(4) On-chip debug security ID setting area
A 10-byte area of 000C4H to 000CDH and 020C4H to 020CDH can be used as an on-chip debug security ID setting
area. Set the on-chip debug security ID of 10 bytes at 000C4H to 000CDH when the boot swap is not used and at
000C4H to 000CDH and at 020C4H to 020CDH when the boot swap is used. For details, see CHAPTER 31 ON-CHIP
DEBUG FUNCTION.

Renesas RL78 Series Specifications

General

Core	RL78
CPU Clock Speed	Up to 32 MHz
Flash Memory	Up to 512 KB
RAM	Up to 32 KB
Operating Voltage	1.6 V to 5.5 V
Low Power Modes	HALT, STOP, SNOOZE
CPU Architecture	16-bit
Temperature Range	-40°C to +85°C
Package	LQFP
Timers	16-bit timers
Communication Interfaces	UART, I2C, LIN
A/D Converter	12-bit
