Renesas RL78 Series User Manual

RL78/F13, F14 CHAPTER 27 SAFETY FUNCTIONS
R01UH0368EJ0210 Rev.2.10 1603
Dec 10, 2015
Notes 1. Code flash memory and RAM address of each product are as follows.
 RL78/F13 (LIN incorporated)
ROM size Code flash memory (00000H to xxxxxH) RAM size RAM(yyyyyH to FFEFFH)
16 Kbytes 16384  8 bits (00000H to 03FFFH)
Note 2
1 Kbyte 1024  8 bits (FFB00H to FFEFFH)
32 Kbytes 32768  8 bits (00000H to 07FFFH)
Note 2
2 Kbytes 2048  8 bits (FF700H to FFEFFH)
48 Kbytes 49152  8 bits (00000H to 0BFFFH)
Note 2
3 Kbytes 3072  8 bits (FF300H to FFEFFH)
64 Kbytes 65536  8 bits (00000H to 0FFFFH) 4 Kbytes 4096  8 bits (FEF00H to FFEFFH)
96 Kbytes 98304  8 bits (00000H to 17FFFH)
Note 3
6 Kbytes 6144  8 bits (FE700H to FFEFFH)
128 Kbytes 131072  8 bits (00000H to 1FFFFH) 8 Kbytes 8192  8 bits (FDF00H to FFEFFH)
 RL78/F13 (CAN and LIN incorporated)
ROM size Code flash memory (00000H to xxxxxH) RAM size RAM (yyyyyH-FFEFFH)
32 Kbytes 32768  8 bits (00000H to 07FFFH)
Note 2
2 Kbytes 2048  8 bits (FF700H to FFEFFH)
48 Kbytes 49152  8 bits (00000H to 0BFFFH)
Note 2
3 Kbytes 3072  8 bits (FF300H to FFEFFH)
64 Kbytes 65536  8 bits (00000H to 0FFFFH) 4 Kbytes 4096  8 bits (FEF00H to FFEFFH)
96 Kbytes 98304  8 bits (00000H to 17FFFH)
Note 3
6 Kbytes 6144  8 bits (FE700H to FFEFFH)
128 Kbytes 131072  8 bits (00000H to 1FFFFH) 8 Kbytes 8192  8 bits (FDF00H to FFEFFH)
 RL78/F14
ROM size Code flash memory (00000H to xxxxxH) RAM size RAM (yyyyyH to FFEFFH)
48 Kbytes 49152  8 bits (00000H to 0BFFFH)
Note 2
4 Kbytes 4096  8 bits (FEF00H to FFEFFH)
64 Kbytes 65536  8 bits (00000H to 0FFFFH) 6 Kbytes 6144  8 bits (FE700H to FFEFFH)
96 Kbytes 98304  8 bits (00000H to 17FFFH)
Note 3
8 Kbytes 8192  8 bits (FDF00H to FFEFFH)
128 Kbytes 131072  8 bits (00000H to 1FFFFH) 10 Kbytes 10240  8 bits (FD700H to FFEFFH)
192 Kbytes 196608  8 bits (00000H to 2FFFFH) 16 Kbytes 16384  8 bits (FBF00H to FFEFFH)
256 Kbytes 262144  8 bits (00000H to 3FFFFH) 20 Kbytes 20480  8 bits (FAF00H to FFEFFH)
2. Fetching of an instruction (for execution) by illegal access to a location in the area from xxxxxH to 0FFFFH
leads to the generation of a reset due to the execution of an illegal instruction rather than being handled as
illegal memory access.
3. Fetching of an instruction (for execution) by illegal access to a location in the area from xxxxxH to 1FFFFH
leads to the generation of a reset due to the execution of an illegal instruction rather than being handled as
illegal memory access.
