RL78/F13, F14 CHAPTER 35 ELECTRICAL SPECIFICATIONS (GRADE K)

R01UH0368EJ0210 Rev.2.10 1769

Dec 10, 2015

Simplified I

C mode connection diagram (during communication at different potential)

Simplified I

C mode serial transfer timing (during communication at different potential)

Caution Select the TTL input buffer and the N-ch open-drain output mode for the SDAr pin and N-ch open-drain

output mode for the SCLr pin.

Remarks 1. R

b [Ω]: Communication line (SDAr, SCLr) pull-up resistance, Cb [F]: Communication line (SDAr, SCLr) load

capacitance, V

b [V]: Communication line voltage

2. f

MCK: Serial array unit operation clock frequency

SDAr

SCLr

SDA

SCL

User's device

RL78

microcontroller

SDAr

LOW

HIGH

HD : DAT

SCLr

SU : DAT

1/f

SCL
