RL78/F13, F14 CHAPTER 35 ELECTRICAL SPECIFICATIONS (GRADE K)
R01UH0368EJ0210 Rev.2.10 1775
Dec 10, 2015
(4) When AVREF (+) = internal reference voltage (ADREFP1 = 1, ADREFP0 = 0), AVREF (-) = AVREFM/ANI1
(ADREFM = 1), target ANI pin: ANI0 to ANI23, ANI24 to ANI30
(TA = -40 to +125C, 2.7 V EVDD0 = EVDD1 = VDD 5.5 V, VSS = EVSS0 = EVSS1 = 0 V, Reference voltage (+) = VBGR,
Reference voltage (-) = AV
REFM = 0 V)
Parameter Symbol Conditions MIN. TYP. MAX. Unit
Resolution RES 8 bit
Conversion time tCONV 8-bit resolution 2.7 V VDD 5.5 V 17 39
µs
Zero-scale error
Notes 1, 2
EZS 8-bit resolution 2.7 V VDD 5.5 V 0.60 %FSR
Integral linearity error
Note 1
ILE 8-bit resolution 2.7 V VDD 5.5 V 2.0 LSB
Differential linearity error
Note 1
DLE 8-bit resolution 2.7 V VDD 5.5 V 1.0 LSB
Reference voltage (+) VBGR 1.38 1.45 1.5 V
Analog input voltage VAIN 0 VBGR V
Notes 1. Excludes quantization error (1/2 LSB).
2. This value is indicated as a ratio (%FSR) to the full-scale value.
