RL78/F13, F14 CHAPTER 36 ELECTRICAL SPECIFICATIONS (GRADE Y)
R01UH0368EJ0210 Rev.2.10 1798
Dec 10, 2015
(TA = -40 to +150C, 2.7 V  EVDD0 = EVDD1 = VDD  5.5 V, VSS = EVSS0 = EVSS1 = 0 V)
Parameter Symbol Conditions MIN. TYP. MAX. Unit
Window watchdog
timer operating
current
I
WDT
Notes 1, 2
fIL = 15 kHz 0.22 A
A/D converter
operating current
I
ADC
Note 3
When
conversion at
maximum
speed
Normal mode, AV
REFP = VDD = 5.0 V 1.3 1.7 mA
When internal reference voltage is selected
Note 5
75.0 A
LVD operating
current
I
LVD
Note 4
0.08 A
Temperature sensor
operating current
I
TMPS 75.0 A
D/A converter
operating current
I
DAC Per channel 0.8 1.5 mA
Comparator operating
current
I
CMP 50.0 A
BGO operating
current
I
BGO
Note 6
2.50 12.20 mA
Notes 1. When the high-speed on-chip oscillator clock and high-speed system clock are stopped.
2. Current flowing only to the watchdog timer (including the operation current of the 1.5 kHz on-chip oscillator).
The current value is the sum of IDD1, IDD2, or IDD3 and IWDT when the watchdog timer operates in STOP mode.
3. Current flowing only to the A/D converter. The current value is the sum of I
DD1 or IDD2 and IADC when the A/D
converter operates in operation mode or HALT mode.
4. Current flowing only to the LVD circuit. The current value is the sum of I
DD1, IDD2, or IDD3 and ILVD when the LVD
circuit operates in operation mode, HALT mode, or STOP mode.
5. Operating current that increases when the internal reference voltage is selected. This current flows even
when conversion is stopped.
6. Current increased by the BGO operation. The current value is the sum of I
DD1 or IDD2 and IBGO when the BGO
operates in operation mode or HALT mode.
