RL78/F13, F14 CHAPTER 3 CPU ARCHITECTURE
R01UH0368EJ0210 Rev.2.10 152
Dec 10, 2015
Table 3-6. Extended SFR (2nd SFR) List (1/32)
Address Special Function Register (2nd SFR) Name Symbol R/W Manipulable Bit Range After reset
1-bit 8-bit 16-bit
F0010H A/D converter mode register 2 ADM2 R/W – 00H
F0011H Conversion result comparison upper limit setting register ADUL R/W – – FFH
F0012H Conversion result comparison lower limit setting register ADLL R/W – – 00H
F0013H A/D test register ADTES R/W – – 00H
F0016H Peripheral I/O redirection register 0 PIOR0 R/W – – 00H
F0017H Peripheral I/O redirection register 1 PIOR1 R/W – – 00H
F0018H Peripheral I/O redirection register 2 PIOR2 R/W – – 00H
F0019H Peripheral I/O redirection register 3 PIOR3 R/W – – 00H
F001AH Peripheral I/O redirection register 4 PIOR4 R/W – – 00H
F001BH Peripheral I/O redirection register 5 PIOR5 R/W – – 00H
F001CH Peripheral I/O redirection register 6 PIOR6 R/W – – 00H
F001DH Peripheral I/O redirection register 7 PIOR7 R/W – – 00H
F001EH Peripheral I/O redirection register 8 PIOR8 R/W – – 00H
F0021H Port input threshold control register 1 PITHL1 R/W – 00H
F0023H Port input threshold control register 3 PITHL3 R/W – 00H
F0024H Port input threshold control register 4 PITHL4 R/W – 00H
F0025H Port input threshold control register 5 PITHL5 R/W – 00H
F0026H Port input threshold control register 6 PITHL6 R/W – 00H
F0027H Port input threshold control register 7 PITHL7 R/W – 00H
F002AH Port input threshold control register 10 PITHL10 R/W – 00H
F002CH Port input threshold control register 12 PITHL12 R/W – 00H
F002FH Port input threshold control register 15 PITHL15 R/W – 00H
F0030H Pull-up resistor option register 0 PU0 R/W – 00H
F0031H Pull-up resistor option register 1 PU1 R/W – 00H
F0033H Pull-up resistor option register 3 PU3 R/W – 00H
F0034H Pull-up resistor option register 4 PU4 R/W – 01H
F0035H Pull-up resistor option register 5 PU5 R/W – 00H
F0036H Pull-up resistor option register 6 PU6 R/W – 00H
F0037H Pull-up resistor option register 7 PU7 R/W – 00H
F0039H Pull-up resistor option register 9 PU9 R/W – 00H
F003AH Pull-up resistor option register 10 PU10 R/W – 00H
F003CH Pull-up resistor option register 12 PU12 R/W – 00H
F003EH Pull-up resistor option register 14 PU14 R/W – 00H
F003FH Pull-up resistor option register 15 PU15 R/W – 00H
F0041H Port input mode register 1 PIM1 R/W – 00H
F0043H Port input mode register 3 PIM3 R/W – 00H
F0045H Port input mode register 5 PIM5 R/W – 00H
F0046H Port input mode register 6 PIM6 R/W – 00H
F0047H Port input mode register 7 PIM7 R/W – 00H
F004CH Port input mode register 12 PIM12 R/W – 00H
F0051H Port output mode register 1 POM1 R/W – 00H
F0056H Port output mode register 6 POM6 R/W – 00H
F0057H Port output mode register 7 POM7 R/W – 00H
