RL78/F13, F14 CHAPTER 3 CPU ARCHITECTURE
R01UH0368EJ0210 Rev.2.10 154
Dec 10, 2015
Table 3-6. Extended SFR (2nd SFR) List (3/32)
Address Special Function Register (2nd SFR) Name Symbol R/W Manipulable Bit Range After reset
1-bit 8-bit 16-bit
F0108H Serial mode register 00 SMR00 R/W – –  0020H
F0109H
F010AH Serial mode register 01 SMR01 R/W – –  0020H
F010BH
F010CH Serial communication operation setting register 00 SCR00 R/W – –  0087H
F010DH
F010EH Serial communication operation setting register 01 SCR01 R/W – –  0087H
F010FH
F0110H Serial channel enable status register SE0L SE0 R    0000H
F0111H – – –
F0112H Serial channel start register 0 SS0L SS0 R/W    0000H
F0113H – – –
F0114H Serial channel stop register 0 ST0L ST0 R/W    0000H
F0115H – – –
F0116H Serial clock select register 0 SPS0L SPS0 R/W –   0000H
F0117H – – –
F0118H Serial output register 0 SO0 R/W – –  0303H
F0119H
F011AH Serial output enable register 0 SOE0L SOE0 R/W    0000H
F011BH – – –
F0120H Serial output level register 0 SOL0L SOL0 R/W –   0000H
F0121H – – –
F0122H Serial slave select enable register 0 SSE0L SSE0 R/W –   0000H
F0123H – – –
F0140H Serial status register 10 SSR10L SSR10 R –   0000H
F0141H – – –
F0142H Serial status register 11 SSR11L SSR11 R –   0000H
F0143H – – –
F0144H Serial flag clear trigger register 10 SIR10L SIR10 R/W –   0000H
F0145H – – –
F0146H Serial flag clear trigger register 11 SIR11L SIR11 R/W –   0000H
F0147H – – –
F0148H Serial mode register 10 SMR10 R/W – –  0020H
F0149H
F014AH Serial mode register 11 SMR11 R/W – –  0020H
F014BH
F014CH Serial communication operation setting register 10 SCR10 R/W – –  0087H
F014DH
F014EH Serial communication operation setting register 11 SCR11 R/W – –  0087H
F014FH
F0150H Serial channel enable status register 1 SE1L SE1 R    0000H
F0151H – – –
