RL78/F13, F14 CHAPTER 4 PORT FUNCTIONS

R01UH0368EJ0210 Rev.2.10 215

Dec 10, 2015

Figure 4-8. Block Diagram of P13

WRPU

PORT

PU13

P13

EVDD

P-ch

PU1

WRPM

PM1

POM13

POM1

WRPOM

PM13

CMOS

(Schmitt3)

TTL

PIM1

PIM13

WRPIM

PITHL1

PITHL13

WRPITHL

CMOS

(Schmitt1)

WRPMS

PMS

PMS0

Alternate function

TRDIOA0/TO04

Alternate function

SDA01/LTXD0

P13/TI04/TO04/

TRDIOA0/TRDCLK0

SI01/SDA01/LTXD0

Alternate function

Internal bus

Selector

Output latch

P1: Port register 1

PU1: Pull-up resistor option register 1

PM1: Port mode register 1

PIM1: Port input mode register 1

POM1: Port output mode register 1

PMS: Port mode select register

PITHL1: Port input threshold control register 1

RD: Read signal

WRxx: Write signal
