RL78/F13, F14 CHAPTER 4 PORT FUNCTIONS

R01UH0368EJ0210 Rev.2.10 224

Dec 10, 2015

Figure 4-15. Block Diagram of P32

P32/TI16/

TO16/INTP7

PORT

PU32

P32

PM32

P-ch

PU3

PM3

TO16

PMS

PMS0

Alternate function

Internal bus

Selector

Output latch

P3: Port register 3

PU3: Pull-up resistor option register 3

PM3: Port mode register 3

PMS: Port mode select register

RD: Read signal

WRxx: Write signal
