RL78/F13, F14 CHAPTER 4 PORT FUNCTIONS

R01UH0368EJ0210 Rev.2.10 299

Dec 10, 2015

Figure 4-68 shows a block diagram of port 14 for 100-pin products.

Figure 4-68. Block Diagram of P140

P140/PCLBUZ0

PORT

WRPM

PU140

P140

PM140

EVDD

P-ch

PU14

PM14

P14

PCLBUZ0

WRPMS

PMS

PMS0

Internal bus

Output latch

Alternate function

Selector

P14: Port register 14

PU14: Pull-up resistor option register 14

PM14: Port mode register 14

PMS: Port mode select register

RD: Read signal

WRxx: Write signal
