RL78/F13, F14 CHAPTER 4 PORT FUNCTIONS
R01UH0368EJ0210 Rev.2.10 311
Dec 10, 2015
Table 4-27. Port Configuration of Products of Groups B to D (80-pin products) (1/4)
Port
Name
Port Bit
Output
Latch
I/O Mode
Control
Pull-up
Control
Input Type
Control
Output
Type
Control
Operating
Mode
Control
Input
Threshold
Control
PORT0 0 P0.0 PM0.0 PU0.0    
1 P0.1 PM0.1 PU0.1
   
2 P0.2 PM0.2 PU0.2
   
3
      
4
      
5
      
6
      
7
      
PORT1 0 P1.0 PM1.0 PU1.0 PIM1.0 POM1.0  PITHL1.0
1 P1.1 PM1.1 PU1.1 PIM1.1 POM1.1  PITHL1.1
2 P1.2 PM1.2 PU1.2  POM1.2  
3 P1.3 PM1.3 PU1.3 PIM1.3 POM1.3  PITHL1.3
4 P1.4 PM1.4 PU1.4 PIM1.4 POM1.4  PITHL1.4
5 P1.5 PM1.5 PU1.5  POM1.5  
6 P1.6 PM1.6 PU1.6 PIM1.6 POM1.6  PITHL1.6
7 P1.7 PM1.7 PU1.7 PIM1.7 POM1.7  PITHL1.7
PORT2 0       
1       
2       
3       
4       
5       
6       
7       
PORT3 0 P3.0 PM3.0 PU3.0 PIM3.0   PITHL3.0
1 P3.1 PM3.1 PU3.1    
2 P3.2 PM3.2 PU3.2    
3 P3.3 PM3.3     
4 P3.4 PM3.4     
5       
6       
7       
PORT4 0 P4.0 PM4.0 PU4.0    
1 P4.1 PM4.1 PU4.1    
2 P4.2 PM4.2 PU4.2    
3 P4.3 PM4.3 PU4.3    PITHL4.3
4 P4.4 PM4.4 PU4.4    
5 P4.5 PM4.5 PU4.5    
6 P4.6 PM4.6 PU4.6    
7 P4.7 PM4.7 PU4.7    
Remark : Not provided.
