RL78/F13, F14 CHAPTER 4 PORT FUNCTIONS

R01UH0368EJ0210 Rev.2.10 329

Dec 10, 2015

PITHLmn Selection of the input buffer threshold for Pmn pins (m = 1, 3 to 7, 10, 12, 15; n = 0 to 7)

0 Schmitt1 input

1 Schmitt3 input

PIMmn PITHLmn

Selection of the input buffer threshold for Pmn pins

(m = 1, 3 to 7, 10, 12, 15; n = 0 to 7)

0 0 Schmitt1 input

0 1 Schmitt3 input

1 0 TTL input

1 1 Setting prohibited

Caution Be sure to set bits for pins that are not present to their initial values.
