RL78/F13, F14 CHAPTER 4 PORT FUNCTIONS

R01UH0368EJ0210 Rev.2.10 335

Dec 10, 2015

Notes 1. Products of Groups C to E only

2. Products of Groups C and D only

3. Group E products only

4. Products of Groups B to E only

5. Products of Groups B to D only

6. The simplified IIC function (SDA and SCL) cannot be used when PIOR is 1.

Cautions 1. The 30- and 20-pin products do not have the PIOR4 register.

2. Set the bit the use of which is prohibited to 0.
