RL78/F13, F14 CHAPTER 4 PORT FUNCTIONS
R01UH0368EJ0210 Rev.2.10 352
Dec 10, 2015
Table 4-29. Settings of Port Mode Register and Output Latch When Using Alternate Function (4/8)
Pin Name Alternate Function PIORXX POMXX PMCXX PMXX PXX PIMXX PITHLXX
Function Name I/O
P40 TOOL0 I/O × – – × × – –
P41 TI10 Input 0 – – 1 × – –
TO10 Output 0 – – 0 0 – –
TRJIO0 Input × – – 1 × – –
Output × – – 0 0 – –
VCOUT0 Output × – – 0 0 – –
SNZOUT2 Output 0 – – 0 0 – –
P42 (LTXD0) Output 1 – – 0 1 – –
P43 (LRXD0) Input 1 – – 1 × – 0/1
P44 (TI07) Input 1 – – 1 × – –
(TO07) Output 1 – – 0 0 – –
P45 (TI10) Input 1 – – 1 × – –
(TO10) Output 1 – – 0 0 – –
P46 (TI12) Input 1 – – 1 × – –
(TO12) Output 1 – – 0 0 – –
P47 INTP13 Input × – – 1 × – –
P50 (SSI01) Input 1 – – 1 × – 0/1
(INTP3) Input 1 – – 1 × – 0/1
P51 INTP11 Input × – – 1 × – –
(SO01) Output 1 – – 0 1 – –
P52 (SCK01) Input 1 – – 1 × – 0/1
Output 1 – – 0 1 – ×
(STOPST)
Note
Output × – – 0 0 – 0/1
P53 INTP10 Input × – – 1 × – 0/1
(SI01) Input 1 – – 1 × – 0/1
P54 SSI10 Input × – – 1 × 0/1 0/1
(TI11) Input 1 – – 1 × 0 0/1
(TO11) Output 1 – – 0 0 × ×
P55 (TI13) Input 1 – – 1 × – –
(TO13) Output 1 – – 0 0 – –
P56 (TI15) Input 1 – – 1 × – –
(TO15) Output 1 – – 0 0 – –
(SNZOUT1) Output 1 – – 0 0 – –
P57 (TI17) Input 1 – – 1 × – –
(TO17) Output 1 – – 0 0 – –
(SNZOUT0) Output 1 – – 0 0 – –
Note The STOPST function can be assigned via settings in the STOP status output control register (STPSTC).
Remarks 1. : Don't care
PIORxx: Peripheral I/O redirection register
POMxx: Port output mode register
PMCxx: Port mode control register
PMxx: Port mode register
Pxx: Port output latch
