Table 4-29. Settings of Port Mode Register and Output Latch When Using Alternate Function (7/8)
Pin Name Alternate Function PIORXX POMXX PMCXX PMXX PXX PIMXX PITHLXX
Function Name I/O
P82 ANI04 Input × – – 1 × – –
IVCMP01 Input × – – 1 × – –
P83 ANI05 Input × – – 1 × – –
IVCMP02 Input × – – 1 × – –
P84 ANI06 Input × – – 1 × – –
IVCMP03 Input × – – 1 × – –
P85 ANI07 Input × – – 1 × – –
IVREF0 Input × – – 1 × – –
P86-P87 ANI08 to ANI09 Input × – – 1 × – –
P90-P95 ANI10 to ANI15 Input × – – 1 × – –
P96-P97 ANI16 to ANI17 Input × – – 1 × – –
ANI26 to ANI27
Note
Input × – 1 1 × – –
P100-
P105
ANI18 to ANI23 Input × – – 1 × – –
P106 (LTXD1) Output 1 – – 0 1 – –
P107 (LRXD1) Input 1 – – 1 × – 0/1
P120 ANI25 Input × × 1 1 × – –
TI07 Input 0 × 0 1 × – –
INTP4 Input × × 0 1 × – –
TRDIOD0 Input 0 × 0 1 × – –
Output 0 0 0 0 0 – –
SO01 Output 0 0/1 0 0 1 – –
TO07 Output 0 0 0 0 0 – –
P125 ANI24 Input × – 1 1 × × ×
TI03 Input 0 – 0 1 × 0 0/1
INTP1 Input × – 0 1 × 0 0/1
TO03 Output 0 – 0 0 0 × ×
TRDIOB0 Input 0 – 0 1 × 0 0/1
Output 0 – 0 0 0 × ×
SSI01 Input 0 – 0 1 × 0/1 0/1
SNZOUT1 Output 0 – 0 0 0 × ×
P126 (TI01) Input 1 – – 1 × – –
(TO01) Output 1 – – 0 0 – –
P127 (TI03) Input 1 – – 1 × – –
(TO03) Output 1 – – 0 0 – –
P130 RESOUT Output × – – – 0 – –
P137 INTP0 Input × – – – × – –
Note In the products of Groups B to D.
Remarks 1. : Don't care
PIORxx: Peripheral I/O redirection register
POMxx: Port output mode register
PMCxx: Port mode control register
PMxx: Port mode register
Pxx: Port output latch
To Next Page
