Notes 1. The following pairs of internal and external sources are each counted as a single source in this number:
INTP4 and INTSPM.
2. The following pairs of internal and external sources are each counted as a single source in this number:
INTP4 and INTSPM, INTP6 and INTTM11H, INTP7 and INTTM13H, INTP8 and INTRTC, INTP9 and
INTTM01H.
3. The following pairs of internal and external sources are each counted as a single source in this number:
INTP4 and INTSPM, INTP6 and INTTM11H, INTP7 and INTTM13H, INTP8 and INTRTC, INTP9 and
INTTM01H, INTP10 and INTTM03H.
4. INTP11 and INTLIN0WUP are counted as a single source because using them at the same time is not
possible.
5. Do not use the XT1 and XT2 pin functions in grade-Y products.
Caution For details, see 1.5 Pin Configurations.
