Renesas RL78 Series User Manual

Conventions Data significance: Higher digits on the left and lower digits on the right
Active low representations:  (overscore over pin and signal name)
Note: Footnote for item marked with Note in the text
Caution: Information requiring particular attention
Remark: Supplementary information
Numerical representations: Binary
...
 or B
Decimal
...

Hexadecimal
...
H
Related Documents The related documents indicated in this publication may include preliminary versions.
However, preliminary versions are not marked as such.
Documents Related to Devices
Document Name Document No.
RL78/F13, F14 User’s Manual: Hardware R01UH0368E
RL78 Family User’s Manual: Software R01US0015E
Documents Related to Flash Memory Programming
Document Name Document No.
PG-FP5 Flash Memory Programmer User’s Manual R20UT0008E
Caution The related documents listed above are subject to change without notice. Be sure to use the latest
version of each document when designing.

Renesas RL78 Series Specifications

General

Core	RL78
CPU Clock Speed	Up to 32 MHz
Flash Memory	Up to 512 KB
RAM	Up to 32 KB
Operating Voltage	1.6 V to 5.5 V
Low Power Modes	HALT, STOP, SNOOZE
CPU Architecture	16-bit
Temperature Range	-40°C to +85°C
Package	LQFP
Timers	16-bit timers
Communication Interfaces	UART, I2C, LIN
A/D Converter	12-bit
