RL78/F13, F14 CHAPTER 9 REAL-TIME CLOCK

R01UH0368EJ0210 Rev.2.10 676

Dec 10, 2015

Here is an example of setting the alarm.

Time of Alarm Day 12-Hour Display 24-Hour Display

Sunday

Monday

Tuesday

Wednesday

Thursday

Friday

Saturday

Hour

Minute

Hour

Minute

Every day, 0:00 a.m. 1 1 1 1 1 1 1 1 2 0 0 0 0 0 0

Every day, 1:30 a.m. 1 1 1 1 1 1 1 0 1 3 0 0 1 3 0

Every day, 11:59 a.m. 1 1 1 1 1 1 1 1 1 5 9 1 1 5 9

Monday through

Friday, 0:00 p.m.

0 1 1 1 1 1 0 3 2 0 0 1 2 0 0

Sunday, 1:30 p.m. 1 0 0 0 0 0 0 2 1 3 0 1 3 3 0

Monday, Wednesday,

Friday, 11:59 p.m.

0 1 0 1 0 1 0 3 1 5 9 2 3 5 9
