(4) 100-pin products
Power Supply Corresponding Pins
EVDD0, EVDD1
 Port pins other than P33, P34, P80 to P87, P90 to P97, P100 to P105, P121 to P124,
and P137
VDD  P33, P34, P80 to P87, P90 to P97, P100 to P105, P121 to P124, and P137
 Pins other than port pins
The products are classified into the following five groups according to the product type, pin count, and code flash
memory size.
Group A: RL78/F13 (LIN incorporated) products with 20, 30, 32, 48, or 64 pins and 16 Kbytes to 64 Kbytes of code
flash memory
Group B: RL78/F13 (LIN incorporated) products with 48 or 64 pins and 96 Kbytes to 128 Kbytes of code flash memory
or with 80 pins and 64 Kbytes to 128 Kbytes of code flash memory
Group C: RL78/F13 (CAN and LIN incorporated) products with 30, 32, 48, 64, or 80 pins and 32 Kbytes to 128 Kbytes
of code flash memory
Group D: RL78/F14 products with 30, 32, 48, 64, or 80 pins and 48 Kbytes to 96 Kbytes of code flash memory
Group E: RL78/F14 products with 48, 64, or 80 pins and 128 Kbytes to 256 Kbytes of code flash memory or with 100
pins and 64 Kbytes to 256 Kbytes of code flash memory
This subchapter describes the 100-pin products of RL78/F14 and the 80-pin products of RL78/F13 (CAN and LIN
incorporated) as examples.

Renesas RL78 Series Specifications

General

Core	RL78
CPU Clock Speed	Up to 32 MHz
Flash Memory	Up to 512 KB
RAM	Up to 32 KB
Operating Voltage	1.6 V to 5.5 V
Low Power Modes	HALT, STOP, SNOOZE
CPU Architecture	16-bit
Temperature Range	-40°C to +85°C
Package	LQFP
Timers	16-bit timers
Communication Interfaces	UART, I2C, LIN
A/D Converter	12-bit
