RL78/F13, F14 CHAPTER 15 SERIAL ARRAY UNIT

R01UH0368EJ0210 Rev.2.10 801

Dec 10, 2015

Figure 15-3. Format of Serial Data Register mn (SDRmn) (mn = 00, 01, 10, 11)

Address: FFF10H, FFF11H (SDR00), FFF12H, FFF13H (SDR01) After reset: 0000H R/W

FFF48H, FFF49H (SDR10), FFF4AH, FFF4BH (SDR11)

15 14 13 12 11 10 9 8 7 6 5 4 3 2 1 0

SDRmn

15 14 13 12 11 10 9 8 7 6 5 4 3 2 1 0

Shift

Remark For the function of the higher 7 bits of the SDRmn register, see 15.3 Registers Controlling Serial Array

Unit.

FFF11H (SDR00)

FFF10H (SDR00)
