RL78/F13, F14 CHAPTER 15 SERIAL ARRAY UNIT

R01UH0368EJ0210 Rev.2.10 831

Dec 10, 2015

Figure 15-24. Each Register Setting When Stopping the Operation by Channels (2/2)

(e) Serial slave select enable register (SSEm) … This register controls the SSImn pin in each slave

channel.

15 14 13 12 11 10 9 8 7 6 5 4 3 2 1 0

SSEm

SSEm1

0/1

SSEm0

0/1

0: Disables the input value of the SSImn pin

Remarks 1. m: Unit number (m = 0, 1), n: Channel number (n = 0, 1)

2. : Setting disabled (set to the initial value)

0/1: Set to 0 or 1 depending on the usage of the user
