RL78/F13, F14 CHAPTER 2 PIN FUNCTIONS

R01UH0368EJ0210 Rev.2.10 56

Dec 10, 2015

Table 2-2. List of RL78/F14 Pins Other than Port Pins (2/5)

Function

I/O Function Pin Count

100-

80-pin 64-pin 48-pin 32-pin 30-pin

KR0 Input Key interrupt input      

KR1 Input      

KR2 Input      

KR3 Input      

KR4 Input      

KR5 Input      

KR6 Input      

KR7 Input      

ANO0 Output D/A converter output      

VCOUT0 Output Comparator output      

TI00 Input 16-bit timer 00 input      

TI01 Input 16-bit timer 01 input (8-bit mode available)      

TI02 Input 16-bit timer 02 input      

TI03 Input 16-bit timer 03 input (8-bit mode available)      

TI04 Input 16-bit timer 04 input      

TI05 Input 16-bit timer 05 input      

TI06 Input 16-bit timer 06 input      

TI07 Input 16-bit timer 07 input      

TI10 Input 16-bit timer 10 input      

TI11 Input 16-bit timer 11 input (8-bit mode available)      

TI12 Input 16-bit timer 12 input      

TI13 Input 16-bit timer 13 input (8-bit mode available)      

TI14 Input 16-bit timer 14 input  

Note 1



Note 1



Note 1

 

TI15 Input 16-bit timer 15 input  

Note 1



Note 1



Note 1

 

TI16 Input 16-bit timer 16 input  

Note 1



Note 1



Note 1

 

TI17 Input 16-bit timer 17 input  

Note 1



Note 1



Note 1

 

TO00 Output 16-bit timer 00 output      

TO01 Output 16-bit timer 01 output (8-bit mode available)      

TO02 Output 16-bit timer 02 output      

TO03 Output 16-bit timer 03 output (8-bit mode available)      

TO04 Output 16-bit timer 04 output      

TO05 Output 16-bit timer 05 output      

TO06 Output 16-bit timer 06 output      

TO07 Output 16-bit timer 07 output      

TO10 Output 16-bit timer 10 output      

TO11 Output 16-bit timer 11 output (8-bit mode available)      

TO12 Output 16-bit timer 12 output      

TO13 Output 16-bit timer 13 output (8-bit mode available)      

TO14 Output 16-bit timer 14 output  

Note 1



Note 1



Note 1

 

TO15 Output 16-bit timer 15 output  

Note 1



Note 1



Note 1

 

TO16 Output 16-bit timer 16 output  

Note 1



Note 1



Note 1

 

TO17 Output 16-bit timer 17 output  

Note 1



Note 1



Note 1

 

Note 1. Provided only in Group E products.
