Renesas RL78 Series User Manual

RL78/F13, F14 CHAPTER 15 SERIAL ARRAY UNIT
R01UH0368EJ0210 Rev.2.10 965
Dec 10, 2015
Figure 15-124. Procedure for Resuming UART Transmission
Port manipulation
Changing setting of the SPSm register
Changing setting of the SDRmn register
Changing setting of the SMRmn register
Changing setting of the SOm register
Port manipulation
Writing to the SSm register
Starting communication
Disable data output of the target channel
by setting a port register and a port mode
register.
Re-set the register to change the
operation clock setting.
Re-set the register to change the
transfer baud rate setting (setting the
transfer clock by dividing the operation
clock (f
MCK )).
Re-set the register to change serial
mode register mn (SMRmn) setting.
Set the initial output level of the serial
data (SOmn).
Enable data output of the target channel
by setting a port register and a port mode
register.
Set the SSmn bit of the target channel to 1 and set
the SEmn bit to 1 (to enable operation).
Set transmit data to the SD
R
mn register
and start communication.
(Essential)
(Selective)
(Essential)
Changing setting of the SOEm register
Set the SOEmn bit to 1 and enable
output.
Changing setting of the SOEm register
Clear the SOEmn bit to 0 and stop output.
(Essential)
Changing setting of the SCRmn register
Re-set the register to change the serial
communication operation setting register
mn (SCRmn) setting.
Changing setting of the SOLm register
Re-set the register to change serial
output level register m (SOLm) setting.
Starting setting for resumption
(Essential)
(Essential)
(Essential)
(Essential)
(Selective)
(Selective)
(Selective)
(Selective)
Remark m: Unit number (m = 0, 1), n: Channel number (n = 0), mn = 00, 10
