• Imaging IOB malfunction
• BCU malfunction
6. Paper Transfer contact/release mechanism defective
• Connector/ harness disconnected
• Motor / Sensor malfunction
• Imaging IOB malfunction
7. Skew Motor in Laser Unit defective
• Connector/ harness disconnected
• Motor malfunction
• Imaging IOB malfunction
Solution:
As SC285-02 is a logging SC (SC Type C), it is not displayed at once when an error occurs. Though the
equipment can be operated, check the SC history and perform a recovery operation if the SC has
occurred.
Countermeasure (1): Large Drifting
An abnormal value may be contained in the SP where the MUSIC corrected result is saved.
1. Execute SP2-180-001 (Line Pos. Adj.: Clear Color Regist.).
6. Troubleshooting
1054
