Ricoh MP C3004 - Printed Circuits Behind the Controller Box

To Next Page

To Previous Page

[A] IPU

[B] BCU

[C] Controller Box Cooling Fan

[D] Controller Board

[E] HDD

Printed Circuits behind the Controller Box

[A] HVP_TTS

[B] Imaging IOB

Electrical Components
