11. Turn ON the main power.
12. Set the paper, and check that the paper size set in the paper feed tray is displayed on the
operation panel.
13. Adjust the registration for the paper feed unit.
SP1-002-004 (Side-to-Side Registration Paper Tray 3)
SP descriptions
• SP1-002 (Side-to-Side Registration)
Adjusts the side-to-side registration by changing the laser main scan start position for each
mode and tray.
Increasing a value: The image is moved towards the rear edge of the paper.
Decreasing a value: The image is moved towards the front edge of the paper.
Changing the paper size
Paper size is set as shown below when the machine is shipped from the factory.
• NA: LT LEF
• EU.AA.CHN: A4 LEF
The paper size can be changed to A4 or LT.
1. Pull out the left tray and right tray.
2. Installation
156
