Drive Unit
MP C4504/C5504/C6004
No. Description No. Description
1 Imaging IOB 7 Registration motor
2 Development motor: CMY 8 PCU motor: CMY
3 Development motor: Black 9 Phase sensor
4 PCU: black motor 10 Fusing motor
5 Paper feed motor 11 Paper exit / pressure release motor
6 Transport motor
