Overview
No. Description No. Description
1 Inner pressure adjustment filter 8 Lubricant bar
2 Development roller 9 Charge roller (non-contact)
3 OPC drum 10 Cleaning roller (charge roller)
4 Cleaning blade 11 Doctor blade
5 Toner collection auger 12 TD sensor
6 Lubricant roller 13 Developer supply coil
7 Lubricant blade 14 Developer collection coil
PCDU (Photo Conductor and Development Unit)
1237
