Air Flow

No. Description No. Description

1 Paper exit cooling fan 6 Imaging Temperature Sensor (Thermistor)

2 Development intake fan/right 7 Drive cooling fan*

3 PSU cooling fan 8 Toner supply cooling fan

4 PSU exhaust fan* 9 Fusing exhaust fan

5 Ozone exhaust fan 10 Main exhaust fan*

MP C4504/C5504/C6004 only
