Ricoh MP C3004 - Controller Cover; Upper Left Cover

3. Pressing down the stopper, slide the front cover [A] to the right and detach it.
Controller Cover
1. Controller cover [A]
Upper Left Cover
• Each part enclosed by a blue circle has a tab. Be careful not to damage it when attaching and
detaching.
4. Replacement and Adjustment
494
