Ricoh MP C3004 - Initial Jam: Cause Code 001; Location Code B

• Replace the Paper Transport IOB.
• Replace the harness.
Target Part/SP No.: Transport Sensor (2nd Feed Tray) / SP5-803-005 (Transport Sensor 2)
Cause verification Problem Judgement
Execute an INPUT check when there is no paper at the position of
the referenced sensor.
0: Paper detected
Execute an INPUT check when there is paper at the position of the
referenced sensor.
1: Paper not detected
Solution:
• Clean the sensor.
• Reconnect the connector.
• Replace the sensor.
• Replace the Paper Transport IOB.
• Replace the harness.
Initial Jam: Cause Code 001 / Location Code B
Target Part/SP No.:Registration Sensor / SP5-803-001
Cause verification Problem Judgement
Execute an INPUT check when there is no paper at the position of
the referenced sensor.
0: Paper detected
Execute an INPUT check when there is paper at the position of the
referenced sensor.
1: Paper not detected
Solution:
• Clean the sensor.
• Reconnect the connector.
• Replace the sensor.
• Replace the Paper Transport IOB.
• Replace the harness.
6. Troubleshooting
1100
