ITB Contact and Release Sensor

1. Image transfer belt unit (page 566)

2. PCDUs (page 553)

3. ITB contact and release sensor bracket [A]

4. ITB contact and release sensor [A]

Image Transfer Lock Unit

1. Open the front cover. (page 493)

4. Replacement and Adjustment

598
