Paper Feed / Transport Section
Changes from the Previous Machine
Items
MP C3003/C3503/
C4503/
C5503/C6003
MP C3004/C3504/C4504/
C5504/C6004
Bypass tray /
Main machine
jam codes
-
The following codes are used to isolate the cause:
• JAM048: Transport Sensor Lag Jam from
Bypass Tray
• JAM051: Transport Sensor Lag Jam from 1st
Feed Tray
Main tray
paper exit
-
• Improved stacking performance by exiting
after adding resilience to the paper with the
paper exit driven roller (drum shape).
• To prevent paper jam when the paper is
delivered from the machine’s paper exit to
the internal exit peripherals, attach the paper
support guide (supplied with the peripherals).
• Replaced the paper exit driven roller to flat
type roller to prevent jamming when paper is
fed to the internal exit peripherals.
1 Action by-
pass feed
Available Not available
Double-feed
detection
Available Not available
Removing
wrinkle in tray
Screwed with L-shaped sheet
metal
Support component and decal
User operable
Paper feed
transport
mechanism
The solenoid removes the
pick-up roller from the paper.
Not available
7. Detailed Descriptions
1262
