Ricoh MP C3004 - [B]: Abnormal Mode: Leds on the Controller Board

Normal situation: POSTCODE LED 8 and BIOS LED blinking for 1 second
No. Note
LED For CPU
- POSTCODE 8 and LED16 blink when the CPU is operating normally.
- POSTCODE 8 and LED16 is lit or off when there is a problem with the CPU.
[B]: Abnormal mode: LEDs on the controller board
LEDs 1 to 8 blink constantly
Troubleshooting for SC Errors
1071
