Ricoh MP C3004 - Mp C3004;C3504

*1 RC-GATE can be fitted to either of the two I/F slots.
*2 There is no difference between the left and right USB port.
MP C3004/C3504
Slot Option
[A] USB mini Used for the PictBridge function.
[B] USB port
*2
• Bluetooth Interface Unit Type D (D566)
• Smart Card Reader Built-in Unit Type M19 (D3BS-22)
• NFC Card Reader Type M19 (D3BS-21)
• External Keyboard Bracket Type M19 (D3BR-10)
• USB Device Server Option Type M19 (D3BC-28, -29)
• Extended USB Board Type M19 (D3BS-01)
[C] I/F slot
• IEEE 1284 Interface Board Type M19 (D3C0)
• File Format Converter Type M19 (D3BR-04)
• IEEE 802.11a/g/n Interface Unit Type M19 (D3BR-01)
• RC-GATE
[D] I/F slot
*1
Fax Option Type M19 (D3BV-01)
*1 Dedicated slot for fax unit
*2 There is no difference between the left and right USB port.
2. Installation
354
