Electrical Components
• Before doing any work, touch a metal object to discharge static electricity from the body. There is a
possibility that the electrical components may malfunction due to static electricity.
• When disconnecting the FFC, release the lock.
• [A]: Disconnect the scanner FFC for the IPU while pressing the lock release button.
• [B]: Disconnect the other FFC while pressing the lock release levers on its sides.
Overview
Printed Circuits/Parts inside the Controller Box
