Ricoh MP C3004 - Scanner Motor

To Next Page

To Previous Page

• When attaching the resin cover, insert its tip under the metal frame.

Scanner Motor

1. Scanner upper cover (page 522)

2. Rear cover (page 499)

3. Grounding plate [A]

Scanner Unit

531
