13. Push the side LCT towards the machine.
14. Turn On the main power.
15. Set the paper, and check that the paper size set in the paper feed tray is displayed on the
control unit.
16. Do the registration adjustment for the large capacity tray.
SP1-002-007 (Side-to-Side Registration Large Capacity Tray)
SP descriptions
SP1-002 (Side-to-Side Registration)
Adjusts the side-to-side registration by changing the laser main scan start position for each mode and
tray.
Increasing a value: The image is moved towards the rear edge of the paper.
Decreasing a value: The image is moved towards the front edge of the paper.
Changing the Paper Size
Paper size is set as shown below when the machine is shipped from the factory.
NA: LT LEF
EU.AA.CHN: A4 LEF
The paper size can be changed to A4, LT, or B5.
1. Open the tray cover.
LCIT RT3030 (D696)
