IEEE 1284 Interface Board Type M19 (D3C0)
Accessories
No. Description Qty Remarks
1 IEEE 1284 Interface Board 1
2 FCC document 1
3 Notes for users 1
Installation procedure
• When installing this option, turn OFF the main power and unplug the power cord from the wall
socket. If installing without turning OFF the main power, an electric shock or a malfunction may
occur.
• Do not put your hand into the controller box. It will result in a malfunction or injury.
• Before doing any work, touch a metal object to discharge static electricity from the body. There is a
possibility that the IEEE 1284 Interface Board may malfunction due to static electricity.
1. Remove the slot cover [A].
MP C4504/C5504/C6004: Remove the exterior cover [B], then remove the left slot cover [A].
IEEE 1284 Interface Board Type M19 (D3C0)
367
