Duplex Entrance Sensor: Lag Jam: Cause Code 067
Target Part/SP No.:Duplex Entrance Sensor / SP5-803-011
Cause verification Problem Judgement
Execute an INPUT check when there is no paper at the
position of the referenced sensor.
0 :Paper detected
Execute an INPUT check when there is paper at the position
of the referenced sensor.
1: Paper not detected
Solution:
• Clean the sensor.
• Reconnect the connector.
• Replace the sensor.
• Replace the Paper Transport IOB.
• Replace the harness.
Target Part/SP No.:Duplex Entrance Motor/ SP5-804-065 (Duplex Entrance
Motor:CW:Standard Speed)
Cause verification Problem Judgement
Turn the referenced motor OFF with OUTPUT check Drive sound heard
Turn the referenced motor ON with OUTPUT check Drive sound not heard
Solution:
• Reconnect the connector.
• Replace the sensor.
• Replace the Paper Transport IOB.
• Replace the harness.
Target Part/SP No.:Duplex/ Bypass Motor / SP5-804-071 (Duplex Bypass
Motor:CW:Standard Speed)
Cause verification Problem Judgement
Turn the referenced motor OFF with OUTPUT check Drive sound heard
Turn the referenced motor ON with OUTPUT check Drive sound not heard
Solution:
Troubleshooting for Transport/Paper Feeding of the Machine
1127
