Waste Toner

Changes from the Previous Machine

Items

MP C3003/C3503/

C4503/

C5503/C6003

MP C3004/C3504/C4504/

C5504/C6004

Waste toner front

door

With latch Without latch

Overview

No. Description No. Description

1 Waste toner bottle full sensor 2 Waste toner bottle set switch

Mechanism

Waste toner bottle set detection

The waste toner bottle set detection switch is at the rear of the waste toner bottle.
