Ricoh MP C3004 - Laser Exposure Unit

To Next Page

To Previous Page

Laser Exposure Unit

No. Description No. Description

1 Skew motor 5 Polygon mirror motor

2 Synchronizing detector board: M/Y-S 6 LD Drive Board (M/Y)

3 Skew motor 7 LD Drive Board (Bk/C)

4 Skew motor 8 Synchronizing detector board: Bk/C-S

7. Detailed Descriptions

1180
