Ricoh MP C3004 - MP C4504;C5504;C6004 Peripherals; Diagram

To Next Page

To Previous Page

Diagram

MP C4504/C5504/C6004 Peripherals

No. Item Code Remarks

1 Banner Paper Guide Tray Type M19 D3BF-00 New

2 Paper Feed Unit PB3150 D694-17, -21 Common (Met-C1)

3 Caster Table Type M3 D178-02 Common (Met-C1)

4 LCIT PB3230

LCIT PB3170

D695-18, -27, -28

D695-27

Common (Met-C1)

5 LCIT RT3030 D696-17, -21, -27 Common (Met-C1)
