Anti-Condensation Heater (Scanner, PCDU)
• Unplug the machine power cord before starting the following procedure.
• Do the following procedure not to damage any harnesses.
• Check that harnesses are not damaged or pinched after installation.
Anti-Condensation Heater (Scanner)
• This option is provided as a service part.
• If you want to install Anti-Condensation Heater (Scanner), (1) heater for scanner and (2) electrical
components should be ordered.
Accessory Check
(1) Heater (lamp) for Scanner
No. Description Q’ty
1 COVER: HEATER: SCANNER 2
2
HEATER:120V:9W
HEATER:230V:9W
1
3 BRACKET HEATER: SCANNER 1
5 SCREW:POLISHED ROUND/SPRING:M4x8 1
6 SCREW M3x3 2
(2) Electrical components
No. Description Q’ty
- TAPPING SCREW M3X6 3
4 CLAMP 6
- HARNESS: SCANNER/PCU 1
- PCB: DHB 1
