Scanning
Changes from the Previous Machine
Items
MP C3003/C3503/C4503/
C5503/C6003
MP C3004/C3504/C4504/
C5504/C6004
Scanner type -
Short focus scanner
*For distortion correction:
After replacing the scanner carriage,
the correction value specified on the
supplied sheet in the SP code must be
entered. For details, see page 524
"Scanner Carriage".
Scanner carriage
storage upon
shipping
None
The scanner carriage must be moved to
lock position to lock the carriage to the
scanner frame before shipping.
Main scanning
magnification
adjustment
None
Magnification adjustment is available
for the main scanning direction with
SP4-871-003, -004.
Overview
The short focus scanner is realized by implementing a lens block (SBU, CCD, and Lens) on the carriage.
After the scanner lamp unit emits the light to the document, the light goes through route shown below
and reaches the CCD.
Scanner lamp unit (LED) -> Original -> 1st mirror (13) -> 2nd mirror (3) -> 3rd mirror (6) -> 2nd mirror
(3) -> 4th mirror (5) -> 5th mirror (14) -> lens -> pre-sensor lens -> CCD
Scanning
1193
